Vacuum Degasser
The vacuum degasser is a device that uses a vacuum pump to evacuate the tank to create negative pressure, and the mud is sucked into the tank, and then processed to further separate the gas in the mud.
Model: HYZCQ240,HYZCQ270,HYZCQ300,HYZCQ360
Brand: HYang, or OEM
Color: Orange, Blue or customized
Degassing efficiency: more than or equal 95%
Treatment capacity: 240~360m3/h (1056~1584gpm)
The vacuum degasser is a device that uses a vacuum pump to evacuate the tank to create negative pressure, and the mud is sucked into the tank, and then processed to further separate the gas in the mud. This degasser is a new type of degasser developed by China on the basis of integrating various types of degasser at home and abroad. It is suitable for various types of mud purification systems. It plays an important role in restoring the specific gravity of the mud. At the same time, it can also be used as a high-power agitator when the mud does not contain gas. It is suitable for degassing distilled water and deionized water in pharmaceutical research, pharmaceutical, chemical, and other industries. It is suitable for all kinds of mud purification systems and plays an important role in restoring the proportion of mud, stabilizing the viscosity of mud, and reducing drilling costs.
The main structural components of the vacuum degasser:
1. Suction pipe 2. Rotor 3. Separation wheel 4. Top cover 5. Method flange 6. Exhaust pipe 7. Vacuum pump 8. Water supply pipe 9. Air-water separator 10. Exhaust short section
Structural advantages:
1. The suction of the vacuum pump is used to make the mud enter the vacuum tank, and the gas is pumped out of the vacuum tank by using it. The vacuum pump plays two different roles here.
2. The water ring vacuum pump is always in an isothermal state during the working process, which is suitable for the suction of flammable and explosive gas and has reliable safety performance.
3. The mud is shot to the four walls at a high speed through the window of the rotor, the bubbles in the mud are broken completely, and the degassing effect is good.
4. The main motor is biased and the center of gravity of the whole machine is lowered.
5. The use of belt transmission avoids the complexity of the deceleration mechanism.
6. The application of the steam-water separator will not cause water and air to be discharged at the same time so that the exhaust pipe is always unblocked. In addition, water can be circulated to the vacuum pump, saving water.
7. The suction pipe is inserted into the mud tank and can be used as a high-power agitator when the mud is not immersed in air.
Model | HYZCQ240 | HYZCQ270 | HYZCQ300 | HYZCQ360 |
Main diameter | 700mm | 800mm | 900mm | 1000mm |
Capacity | ≤240 m3/h (1056GPM) | ≤270 m3/h (1188GPM) | ≤300 m3/h (1320GPM) | ≤360 m3/h (1584GPM) |
Vacuum Degree | -0.02~-0.04 Mpa | |||
Handling Efficiency | ≥95% | |||
Main Motor | 15Kw(20HP) | 22Kw (30HP) | 30Kw(40HP) | 37Kw (50HP) |
Vacuum Pump | 2.2Kw(2.9HP) | 3Kw(4HP) | 4Kw(5.3HP) | 7.5Kw (10 HP) |
Rotation Speed | 860RPM | 870RPM | 876RPM | 880RPM |
EX Standard | ExdⅡBt4 / IECEX / ATEX | |||
Suction Line Size | 6 Inch | |||
Output Size | 8 Inch | |||
Weight | 1100kg | 1350kg | 1650kg | 1800kg |
Dimension: L×W×H | 1750×860×1500mm | 2000×1000×1670mm | 2250×1330×1650mm | 2400×1500×1850mm |
