Decanter Centrifuge

1.VDF HIGH SPEED
2.Separation Point: 2-5um
3.ABB/Siemens Electrical Cabinet

Features and Benefits

1. Adopts 2205 duplex stainless steel for straight and cone section, and also centrifugal casting process.
2. Adopts SS316L for the remaining components of the drum assembly.
3. Spiral conveyor is protected by wear-resistant tungsten carbide alloy plate, long service life and the east to maintain and replace. The branch mouth of the conveyor and solids outlet of the centrifuge bowl are both protected by a wear-resistant alloy sheath which is easy to replace, lengthen the usage life, and maintenance cycle.

5. Drum assembly is protected by dismantled support during transportation, preventing damage to bearings in the transportation.
6. Famous brands SKF and NSK bearings to improve the machine's stability and long service life.
7. Adopts variable frequency control to it’s convenient for users to adjust rotation speed anytime for different working situations.
8. Electrical components are famous international brands like Schneider or Siemens, selects current overload protection and mechanical limit switch double protection.

Model	HYLW600B-1	HYLW450N-1	HYLW450N-2	HYLW355N-1	HYLW355NB-1
Bowl Diameter	600mm	450mm	450mm	355mm	355mm
Bowl Length	1500mm	1000mm	1250mm	1250mm	1250mm
Bowl Speed	2200r/min	2200r/min	3200r/min	3200r/min	0～3200r/min
Treatment Capacity	90㎥/h (396GPM)	50㎥/h(220GPM)	50㎥/h(220GPM)	40㎥/h(176GPM)	40㎥/h(176GPM)
G-Force	815	815	2035	2035	0～2035
Separation point	5～7μm	5～7μm	2～5μm	2～7μm
Separation point	40r/min	40r/min	30r/min	30r/min	0-30r/min
Gear Box Ration	35:1		57:1
Main Drive Motor	55kw	30kw	37kw	30kw	37kw
Back Drive Motor	15kw	7.5kw	7.5kw	7.5kw	7.5kw
EX Standard	ExdIIBt4 / IECEX / A-TEX
Wright	4800kg	2700kg	3200kg	2900kg	3200kg
Dimension	2900×1900×1750mm	2600×1860×1750mm	2600×1860×1750mm	2600×1620×1750mm	2600×1620×1750mm
